Specification
O.D.





Nominal
weight



Calculation of weight GRADE



W.T.





Thickening type



in mm lb/ft kg/m in mm
2 3/8 60.3 6.65 6.26 9.32 E,X,G,S 0.280 7.11 EU
2 7/8 73.0 10.4 9.72 14.48 E,X,G,S 0.362 9.19 EU / IU
3 1/2 88.9 9.50 8.81 13.12 E 0.254 6.45 EU / IU
3 1/2 88.9 13.30 12.31 18.34 E,X,G,S 0.368 9.35 EU /IU
3 1/2 88.9 15.50 14.63 21.79 E 0.449 11.40 EU / IU
3 1/2 88.9 15.50 14.63 21.79 X,G,S 0.449 11.40 EU / IEU
4 101.6 14.00 12.93 19.26 E,X,G,S 0.330 8.38 EU /IU
4 1/2 114.3 13.75 12.24 18.23 E 0.271 6.88 EU /IU
4 1/2 114.3 16.60 14.98 22.31 E,X,G,S 0.337 8.56 EU / IEU
4 1/2 114.3 20.00 18.69 27.84 E,X,G,S 0.430 10.92 EU / IEU
5 127.0 16.25 14.87 22.15 X,G,S 0.296 7.52 IU
5 127.0 19.50 17.93 26.71 E 0.362 9.19 IEU
5 127.0 19.50 17.93 26.71 X,G,S 0.362 9.19 EU / IEU
5 127.0 25.60 24.03 35.79 E 0.500 12.70 IEU
5 127.0 25.60 24.03 35.79 X,G,S 0.500 12.70 EU /IEU
5 1/2 139.7 21.90 19.81 29.51 E,X,G,S 0.361 9.17 IEU
5 1/2 139.7 24.70 22.54 33.57 E,X,G,S 0.415 10.54 IEU
6 5/8 168.3













EU / IEU
