Specifications and sizes of hammer union
Product details
|
Nominal pipe size |
Total length |
Nut radius |
Material |
Weight |
|||||
|
Nut |
Part |
||||||||
|
in |
mm |
in |
mm |
in |
mm |
|
|
lb |
kg |
|
1 |
25.4 |
2-11/16 |
68.3 |
1-15/16 |
49.2 |
SC/SF |
CDB/SF |
1.75 |
0.8 |
|
1-1/4 |
31.7 |
2-7/8 |
73.0 |
2-3/8 |
60.3 |
SF |
SF |
2.37 |
1.1 |
|
1-1/2 |
38.1 |
2-7/8 |
73.0 |
2-3/8 |
60.3 |
SF |
SF |
2.37 |
5.4 |
|
2 |
50.8 |
3-5/16 |
84.1 |
2-29/32 |
73.8 |
SF |
SF |
5.25 |
2.4 |
|
2-1/2 |
63.8 |
4-1/16 |
103.2 |
3-11/16 |
93.7 |
SF |
SF |
10.0 |
4.5 |
|
3 |
76.2 |
4-3/8 |
111.1 |
3-7/8 |
98.4 |
SF |
SF |
15.25 |
6.9 |
|
4 |
101.6 |
4-13/16 |
122.2 |
5 |
127.0 |
SF |
SF |
20.0 |
9.1 |
|
6 |
152.4 |
6-5/8 |
168.3 |
6-7/16 |
163.5 |
SF |
SF |
44.5 |
20.2 |
